15.6 Inch Full HD Digital Touch Screen – Android 11

  • Model: SDST156X7-01
  • Size: 15.6-inch Digital Screen
  • Resolution: Full HD – 1920×1080
  • Energy Class: G
  • Touch Technology: Capacitive with 10 touch points
  • Built-in Media Player: Equipped with a built-in media player powered by Android 11
  • LED Frame: Adjustable LED lights for customizable aesthetics
  • Power Over Ethernet (PoE): Combines power and internet in a single connection for a tidy installation
  • Applications: Ideal for interactive presentations and customer engagement in retail, corporate meetings, educational settings, and public spaces.
Secure Payment Methods

The SWEDX 15.6 Inch Full HD Digital Touch Screen combines high-resolution image quality with advanced interactive touch features. This innovative screen is a powerful tool for businesses aiming to enhance customer engagement, strengthen brand identity, and improve information delivery, offering a modern alternative to traditional signage.

Key Features:

  • Full HD Screen: 15.6 Inch Full HD Digital Touch Screen with a resolution of 1920 x 1080 pixels ensures crystal-clear and detailed content presentation.
  • Capacitive Touch Screen: Equipped with capacitive touch technology, supporting up to 10 simultaneous touch points for a seamless and engaging user experience.
  • Power Over Ethernet (PoE): Supports PoE for combined power and internet connection through a single Ethernet cable, simplifying installation and reducing cable clutter.
  • Built-in Media Player: The screen is equipped with a powerful processor and GPU, supporting advanced graphics standards and offering fast performance for multimedia. Built-in Wi-Fi 6 and Bluetooth 5.0 ensure fast and reliable wireless connections.
  • Versatile Touch Screen: Perfect for diverse applications such as POS screens, meeting room indicators, or interactive sales tools in various industries.
  • User-Friendly Features: Includes playlist creation for automatic playback of images and videos and a timer for automatic on/off functionality.
  • Customizable LED Frame: Adjustable LED lights on the frame can be customized to match branding or set a specific ambiance, or turned off entirely.

The SWEDX 15.6 Inch Full HD Digital Touch Screen is more than just a screen—it’s an innovative solution for businesses looking to captivate and engage audiences with high-quality, interactive content. Whether in retail, corporate environments, education, or public spaces, this screen is designed to provide an unforgettable visual and interactive experience.

FEATURES
  • Size Inch
    65"
    Number of Pixels
    3840x2160
  • Active Display Area (mm)
    1429(H) x 804(V)
    Aspect Ratio
    16:9
  • Refresh Rate
    60Hz
    Brightness (cd/m²) Peak White Luminance Max
    450
  • Peak White Luminance Ratio
    95%
    Contrast Ratio Type
    4000:1 Static. 100 000:1 Dynamic
  • Viewing Angle
    178/178
    Response Time
    6.5 ms
TOUCH
  • Touch Technology
    Points
    N/A
  • Touch Resolution
    32768x32768
    Glass Thickness
    4 mm Anti-Bacteria & Anti-Glare Tempered Glass
POWER AND ECO DESIGN
  • Power Supply
    100–240 V ~ 50/60 Hz
    Power Consumption
    270 W
  • Power Consumption Stand-By
    0.50 W
    Energy Class
    G
  • Lead Presence
    Yes
    Mercury
    0 mg
AUDIO
  • Audio Out
    2 x 20W

DIMENSIONS AND WEIGHT
  • Outline Dimension
    1488.4 x 892 x 91.6 mm
    Package Dimension
    1610 x 190 x 1020 mm
  • Weight
    38 kg
    Weight Package
    45 kg
  • VESA
    400 x 400 mm
STANDARD CONFIGURATION
  • Processor
    Cortex-A72 Quad-Core 2.2GHz - Cortex-A53 Quad-Core 1.8GHz
    GPU
    Mali-G52 MC3 @ 1GHz
  • RAM
    16 GB
    Flash
    256 GB EMMC
  • USB
    1 x USB 3.0 HOST, 5 x USB2.0 OTG
    TF Card
    32GB
  • HDMI IN
    1
    HDMI Version
    1.4
  • HDMI Out
    1
    LAN
    Support RJ45 R/A 10M/100M/1000M Ethernet
  • Multimedia
    Supports Video, Audio, and Image Formats For Smooth Playback of Multimedia Content
    WLAN/WiFi/BT
    2.4GHz/5GHz, Wi-Fi 6, support Wi-Fi 802.11b/g/n
  • Android Version
    14
    USB Media Player
  • Supported OS
ENVIRONMENTAL
  • Operating Temperature
    Storage Temperature
  • Operating Ambient Humidity
    Storage Humidity

Additional information

Weight 38 kg
Dimensions 44 × 35 × 7.6 cm
